GR-LP313
Size
Sale price
$82.17
Regular price $65.74Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) X SwitchTip. Reverse the SwitchTip to easily clear clogs.
This low pressure, high production tip produces a 10 to 12 inch fan pattern and a 0.015 inch orifice.
For large surface areas such as walls, ceilings and floors.
-
Less Prep & Clean-up Time
- Less mess with less overspray
- Put the paint where you want it
-
Easiest Pattern Overlap
- Softer spray fan pattern
- Easy to apply any material to any surface
- Consistent blended finish quality
-
Extended Life
- Spraying at half pressure doubles tip life
- Reduced sprayer maintenance - up to 2X life
-
SmartTip Technology
- Exclusive internal tip geometry
- Reduces energy required to atomise paints, stains, and other materials
- Delivers a superior finish with less pressure
- Works with SmartControl on select Graco sprayers
-
Best Tip on the Market
- Works with any airless sprayer
- Longest lasting fan pattern
- Highest quality finish with a consistent spray pattern
-
Easy to Identify Tip Size
- Large raised tip size numbers are always legible “ even when covered with paint
- Large raised tip size numbers are always legible “ even when covered with paint
-
Superior Tip Design
- Locking tab ensures tip stays securely in guard
- Snaps tip in spray or reverse position
- OneSeal tip gasket installs with no tools
- Solvent seal available when using extremely hot solvents
Spray Chart
| Tip | Fan Pattern Size | Orifice |
| 313 |
15 - 20 cm |
0.013" |
| 315 |
15 - 20 cm |
0.015" |
| 415 |
20 - 25 cm |
0.015" |
| 417 |
20 - 25 cm | 0.017" |
| 419 |
20 - 25 cm | 0.019" |
| 421 |
20 - 25 cm | 0.021" |
| 423 |
20 - 25 cm | 0.023" |
| 425 |
20 - 25 cm | 0.025" |
| 515 |
25 - 30 cm | 0.015" |
| 517 |
25 - 30 cm | 0.017" |
| 519 | 25 - 30 cm | 0.019" |
| 521 | 25 - 30 cm | 0.021" |
| 523 | 25 - 30 cm | 0.023" |
| 525 | 25 - 30 cm | 0.025" |
| 527 | 25 - 30 cm | 0.027" |
| 617 | 30 - 35 cm | 0.017" |
| 619 | 30 - 35 cm | 0.019" |
| 621 | 30 - 35 cm | 0.021" |
| 623 | 30 - 35 cm | 0.023" |
| 625 | 30 - 35 cm | 0.025" |
| 627 | 30 - 35 cm | 0.027" |
| 629 | 30 - 35 cm | 0.029" |
| 631 | 30 - 35 cm | 0.031" |
| 723 | 35 - 40 cm | 0.023" |
| 725 | 35 - 40 cm | 0.025" |
| 729 | 35 - 40 cm | 0.029" |
| 731 | 35 - 40 cm | 0.031" |
